The EVO MFG Front and Rear LCG Bolt-On Coilover kits come complete with all necessary parts to easily convert the JK from the limited coil and shock system to a far superior performing coilover system. 12”’s of usable wheel travel, custom built brackets for the lowest center of gravity, EVO’s legendary SPEC valving and spring rates specifically dialed in for the JK to yield excellent handling. The EVO MFG LCG Bolt-On Coilover system proves to set the bar, for ease of install, price and performance. LCG 3”-5” recommended lift height, fully adjustable minimal drilling/cutting required, fully bolt-on Hi Clearance design. Retains all factory rear exhaust system as well as factory front and rear swaybars.

The EVO MFG Draglink Flip Kit raises trackbar mounting location 3” at the axle to help correct roll center and steering angles of a lifted JK. Roll center is greatly improved giving better handling/ steering response of the vehicle on and off road. The EVO MFG Drag Link Flip Kit features an improved steering stabilizer mounting location to get it up and out of harm’s way above the tie rod.

The EVO MFG High Clearance PRO Long Arm Upgrade kit features the EVO MFG Adjustors, full on car adjustability of control arm length, proven Currie Johnny Joints are used on both ends of each arm, rebuildable, greaseable, and isolated construction for decreased transmission of road vibrations, the ability to retain the factory high clearance transmission cross-member, (welding required). This is a 4 Link Front and Rear Suspension System.

High Clearance Fenders Recommended. Suspension system fits all year and model Jeep Wrangler JK/JKUs

2Door JK: Front (or exhuast spacer kit) and rear aftermarket driveshaft required. (not included)

4Door JKU: Front aftermarket driveshaft or exhaust spacer required, rear driveshaft recommended. (not included)

Recommended wheel backspacing 3.75” or less (smaller backspacing #). Exhaust modifactions required on 2010+ JK/JKUs

LONG ARM LOWER CONTROL ARM OPTIONS:

EVO Manufacturing offers the option of DOM steel tube lower control arms or the upgrade of billet aluminum ENVY Link lower control arms with replaceable steel skid plates. ENVY Links have the option of being raw aluminum or gold anodized.

*DOM STEEL TUBE LOWER CONTROL ARMS

2.0 x .25 WALL DOM STEEL TUBE LINKS POWDER COATED BLACK

*ALUMINUM ENVY LINKS:

BILLET ALUMINUM WITH REPLACEABLE STEEL SKID PLATES

OPTIONAL RAW ALUMINUM OR GOLD ANODIZING


Stated lift range is variable on build, added/removed accesories weight and owners needs .Some installer adjustments to coil may be needed to accommodate owners needs and build requirements
